| Place of Origin: | China |
|---|---|
| Brand Name: | Yida |
| Certification: | CE, EMC, FCC, CCC, RoHS |
| Model Number: | LCD Whiteboard |
| Minimum Order Quantity: | 1 set |
| Price: | $350 - $850 per sets |
| Packaging Details: | Honeycomb Carton/Plywood Case |
| Delivery Time: | 3~7 working days |
| Payment Terms: | L/C, D/P, T/T, Western Union |
| Supply Ability: | 8,000 sets/month |
| Product Name: | Digital Touch Panel | Screen Size: | 65" 75" 86" |
|---|---|---|---|
| Resolution: | 1920*1080/3840*2160 | Contrast Ratio: | 4000:1 |
| Brightness: | 350cd/m2 | Touch Screen: | IR Multi Touch |
| OS: | Android, Windows | Warranty: | 1 Year |
| Installation Way: | Floor Standing, Wall-mounting | Application: | Education,Conference |
| High Light: | 350nits Conference Interactive Whiteboard,CCC Conference Interactive Whiteboard,3840*2160 Digital Touch Panel Whiteboard |
||
Digital Smart Board Solution For Teaching & Conference !
An interactive whiteboard, also known as interactive board or smart board, is a large interactive display board in the form factor of a whiteboard. It can either be a standalone touchscreen comouter used independently to perform tasks and operations, or a connectable apparatus used as a touchpad to control computers from a projector. They are used in a variety of settings, including classrooms at all levels of education, in corporate board rooms and work groups, in training rooms for professional sports coaching, in broadcasting studios, and others.
Touch Board Features
1. You no longer have to purchase expensive projector lamps and experience unexpected burn outs.
2. Shadowing on a projected image is eliminated.
3. Projector light shinning in users eyes, eliminated.
4. Maintenance to change filters on a projector, eliminated.
5. Much cleaner and crisp image than a projector is capable of producing.
6. Display will not be washed out by sun or ambient light.
7. Less wiring than a traditional interactive system.
8. Many units are available with an optional built in PC. This makes a true "All in One" system.
9. More durable surface than traditional whiteboards.
|
Specifications
|
|
|
Panel size
|
32"/42"/50"/55"/60"/65"/70"/75"/86"/98"
|
|
CPU
|
intel i3 (intel i5/i7 option)
|
|
RAM
|
4GB RAM (8GB/16GB option)
|
|
Memory
|
120GB SSD;(240GB SSD/1TB HDD option)
|
|
Windows OS
|
Windows 7/10 without license( license option)
|
|
Android OS option
|
MSD 648 Quad core
|
|
Touch points
|
10/20 points
|
|
Resolution
|
1920*1080 FHD (3840*2160 UHD option)
|
|
Display color
|
16.7M
|
|
Brightness (nits)
|
450cd/㎡
|
|
Contrast
|
5000:1
|
|
Response time
|
8ms
|
|
Life(hrs)
|
>60,000(hrs)
|
|
Front Buttons
|
|
|
PC power button*1;Volume up*1;Volume down *1;Memu*1;Power on/off*1
|
|
|
Front Ports
|
|
|
HDMI*1;Touch out*1;MV in*1;USB2.0*3
|
|
|
Back Ports (Exact ports info. depends on the model of OPS PC)
|
|
|
USB2.0 type B*1;USB2.0*2;HDMI*1;VGA*1
|
|
|
DC(9V-12V)*1;MIC*1;AUDIO*1;LAN*1;USB3.0*2;USB2.0*2;HDMI*1;VGA*1
|
|
|
Power
|
|
|
Power input
|
AC100V-220V, 50-60Hz
|
|
Power of speaker
|
8Ω10W*2
|
|
Standby power consumption
|
3W
|
|
Temperature & Shape
|
|
|
Working temperature
|
0-50℃
|
|
Storage temperature
|
-20/60℃
|
|
Cabinet color/appearance
|
White, black, customized
|
|
Frame material
|
Aluminum/Customized
|
|
Installation
|
Wall mounted/Floor standing
|
|
Accessories
|
|
|
Wall bracket/movable floor stand/pen/remote control/WIFI antenna
|
|
Digital LCD Panel Functions
1. Common interface front, speaker front, digital audio output, support full-channel touch, touch channel automatic switching, gesture recognition, smart control, remote control integrated computer shortcut keys, smart eye protection, one-key switch.
2. Optional built-in camera, remote participants can see the scene during the network video conference.
3. Optional built-in array microphone function, during network video conference, both on-site and remote can hear the voice of each other's explanation.
4. Detachable infrared frame structure design.
5. Optional high-precision 20-point real touch with an accuracy of 1mm.
Why Choose Us
1. Over 6 Years Experience on LCD Display Screen Manufacturing in China.
2. 1-3 Years High Quality Warranty Provided.
3. 3% Free Spare Parts for Your Orders.
4. Global Quality Standard with CE, ROHS, ETL, UL, FCC Certificated.
5. Overseas Customer in 37 Countries in The Wolrd.
6. Full Capable to Provide the Tailor Work of OEM, ODM.
