| Place of Origin: | China |
|---|---|
| Brand Name: | Yida LCD |
| Certification: | RoHS, CE, CCC, FCC, UL, ISO9001 |
| Model Number: | LCD Video Wall |
| Minimum Order Quantity: | 1 pcs |
| Price: | $320 - $950 per piece |
| Packaging Details: | Plywood Case |
| Delivery Time: | 3-10 working days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union |
| Supply Ability: | 12,000 pcs per week |
| Product Name: | Wall Mount LCD Display | Panel Size: | 46" / 49" / 55" / 65" / 75" |
|---|---|---|---|
| Blacklight: | LED Blacklight | Panel Brand: | Samsung / LG |
| Bezel: | 0.8mm / 1.8mm / 3.5mm | Max. Resolution: | 1920*1080 |
| Viewing Angle: | 178° / 178° | Brightness: | 700cd/m2 |
| Lifetime: | 60,000 Hours | Application: | Exhibition, Conference, Commercial, Monitoring |
Wall Mount LCD Display Quick Details
1. Samsung/LG original panel wall mount LCD display in the resolution of 1920*1080.
2. Super narrow bezel of 0.88mm 3.5mm and brightness of 450 units.
3. Random installation support like 2*2, 3*3, 4*4, 4*5 etc.
4. To be installed on the wall or stand on the floor, can be with a floor-standing cabinet or stand bracket with your own decoration.
5. Front-maintenance bracket is also an option.
6. Full-screen displaying and each screen displaying different content support, also random screen combination display full screen also support.
7. 1.5M length HDMI cable, 1.5M length Lan cable, 1.8M length power cable, and software to be provided for free.
8. Processor and matrix on option.
9. To be widely used in shopping malls, offices, monitoring systems,s, etc.
DID Panel Parameters
| Metal Frame | Material | Metal | ||
| Dimensions | 1029.2*583.8*112.5mm | 1023.98*578.57*134.2mm | 1213.5*684.3*122mm | |
| Bezel Width(Total) | 7.5mm | 5.5mm | 3.9mm | |
| Net weight | 18.5KG | 20KG | 30KG | |
| LCD Panel | Panel brand | Kontech | Samsung | Samsung |
| Screen Diagonal | 46inch | 46inch | 55inch | |
| Pixel Pitch(WxH) | 0.53025x 0.53025mm | 0.630x0.630mm | ||
| Color Temprature | 10000K | |||
| Display Area(WxH) | 1029.2*583.8mm | 1023.98*578.57mm | 1213.5*684.3mm | |
| Aspect Ratio | 16 :9 | |||
| Contrast(Typical) | 3500:1 | |||
| Resolution (H x V) | 1920 X 1080 | |||
| Brightness(Typical) | 700cd/m2 | 500cd/m2 | 500cd/m2 | |
| Display Colors | 16.7M(8bit) | |||
| Response Time(Typical) | 8ms | 8ms | 8ms | |
| View Angle | 178°/178° | 178°/178° | 164/164° | |
| Operating Life Time | ≥50,000hours | |||
| Interface | HDMI | 1x HDMI interface input, support 1080P | ||
| DVI | 1x DVI digital signal input, support 1080P | |||
| VGA | 1x VGA analog signal input, support 1080P | |||
| CVBS IN | 2x video input, support NTSC, PAL & SECAM. | |||
| USB | For software updating, HD base map function | |||
| RS232 | A serial port ring out controls A, adopt 568B standard | |||
| RS232 | A serial port ring out controls computer | |||
| Feature | 1. Ultra-narrow frame(3.5mm), enjoy seamlessly visual experience. 2. Native resolution up to 1920×1080, viewing angle up to 178°. 3. Built-in 3D noise reduction technology 4. Embedded 3D color separation unit. 5. High reliability, support non-stop work for 24 hours, suitable to use as a monitor. 6. Flicker-free, Less radiation, Less heat release, no lead, mercury, and other harmful substances. 7. Particular block design support multiple art combinations. Maximum support(15×15). 8. Low power consumption, standby <3W. 9. Integrated multi-channel video signal source, Support HDMI, DVI, VGA, CVBS etc. and USB video playback. |
|||
| Power Supply | AC Power Range | 100V-240V | ||
| Working Temperature | 0~50℃ | |||
| Working Humidity | 10~90% RH | |||
| Accessories | Power Cable | YES | ||
| Remote Controller | YES | |||
| Wall-mounted bracket | TBD | |||
| OSD Language | YES: Chinese, English, etc. | |||
| Package | Hard Carton | |||
| Warranty | YES, one-year warranty. During this period, if any defect happens due to supplier issues, Kontech offers all necessary parts free of charge. | |||
LCD Video Wall Advantages
1. Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
2. High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as a stable and clear image.
3. Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
4. Low power consumption and low heat radiation
5. Long service life lowers the cost of usage and maintenance
6. Innovative and advanced: 42" to 60" Ultra-thin bezel wall mount LCD display, the thinnest bezel up to 1.8mm
7. Ultrathin and lightweight: The ultra-thin and lightweight design make it easy to transport and install.
8. Economical and practical: High performance and high quality make it cost less.
Digital Signage Descriptions
1. Excellent ultra-narrow bezel design with just a 3.5 mm bezel width between screens.
2. Built-in 3D noise reduction, making the image clean and outline more vivid.
3. Full HD display 3840x2160 display.
4. LED backlit technology brings you the perfect visual effect.
5. 4K input supported.
55Inch LCD Panel Specifications
1. Wall Mount LCD Display
High-definition large screen. Limited screen, infinite horizon.
2. Ultra Bezel Perfect Vision
The ultra width of bezel-to-bezel is just 0.3mm, which brings a stunning visual experience.
3. Flexible Installation
Support landscape or portrait display to meet the needs of different occasions.
4. Easy to Remote Control
Smart control software realizes real-time control for the wall mount LCD display via the connection of the RS232 interface, with humanized operation system. No need for support from the database. It's simple, friendly usage, and easy maintenance.
5. Split Screen As Your Wish
4K LCD Screens Applications
Our Service
1. All parts from us warranty time is 12 months.
2. We guarantee that all wall mount LCD display is tested carefully and works very well before shipment. We strive for 100% customer satisfaction on every sale we complete.
3. During the warranty period, we can repair or replace the defective unit for free, after the warranty time, we repair the defective unit and charge part cost.
4. When you receive the package, please open and check it before signing, if it's damaged, ask for a "Damage proof" from the delivery company.
5. For Any query, please contact us by email or Trade Manager, emails will be responded to within 12 working hours
FAQ
1. Q: Are you a factory or trading company?
-A: We are an OEM&ODM factory.
2. Q: What payment methods does your company accept?
-A: We accept most of the payment methods, but mainly accept T/T, L/C, Western Union, and Paypal.
3. Q: How long is the warranty time for your wall mount LCD display?
-A: Our officially promised warranty time is one whole year after delivery at best.
4. Q: I haven't done business with you guys before, how can I trust your company?
-A: And we've got quite a lot of authority certificates, for example, CE, RoHS, FCC, ISO9001, etc. I hope the above will be persuasive enough. Our Trade Assurance Limit is US $500,000, and it is still going up.
5. Q: What are the shipment terms and delivery time of your company?
-A: Well, the depends on the quantity of your order. As you know, we need time to manufacture the machines. But mostly, the shipment time is 3-8 working days after delivery. For delivery way, for Sample&Bulk orders <100KG, we will kindly suggest Express and Air freight, when Air freight and Sea shipping for Bulk orders>100KG, as for detailed cost, it depends on your final order.
6. Q: Do you give me any discount?
-A: I'm sure trying my best to help you get those at the best price and good service at the same time.
