| Place of Origin: | China |
|---|---|
| Brand Name: | YD LCD |
| Certification: | FCC,UL,ISO9001 |
| Model Number: | WM Series |
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | Plywood Case with Foam Protect |
| Delivery Time: | 8-10 days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 1000 units per week |
| Type: | TFT | Application: | Indoor |
|---|---|---|---|
| Panel Size: | 55inch | Spliced Edges: | 3.5mm/8mm |
| Viewing Angle: | 170 Degree | Contrast Ratio: | 3000:1 |
| Brightness: | 450cd/Sqm | Lifetime: | 60000hours |
| High Light: | 55 Inch Wall Mounted Digital Signage,TFT Wall Mounted Digital Signage,450cd/Sqm LCD Video Wall Display |
||
Indoor TV Wall Feature:
1. Narrow design: the narrowest can reach 3.5mm (55did), and it truly achieves the seamless.
2. Interface type: VGA, DVI and HD connected analog signal and digital high-definition signal
3. Remote control function: by RS232 port and Ethernet connection for remote operation
4. Beautiful wall structure design, be convenient for installation and maintenance
5. Continuous boot for 7 * 24 hours, deserve to trust.
6. Support 365 days non-stop boot, the backlight life is up to 60,000 hours
7. Splicing mode is optional.
8. Support error and compensation function of video wall pictures
9. Modular design according to customer demand (M * N)
10. Diversification of the display mode
11. Excellent display
LCD TV Specification:
| Panel Size | 46" | 49" | 55" | 65" |
| Panel Brand | Samsung | LG | Samsung/LG | Samsung |
| Model | HBY-PJ460P | HBY-PJ490P | HBY-PJ550P | HBY-PJ650G |
| Pixel Pitch | 0.53025*0.53025mm | 0.55926*0.55926mm | 0.63*0.63mm | 0.372*0.372mm |
| Viewing Angle | 178H/178V | |||
| Response Time | <6ms | |||
| Display Color | 8Bit,16.7M | |||
| Contrast Ratio | 3500:1 | 1300:1 | 4500:1 | 4000:1 |
| Connectivity | HDMI/DVI/VGA/AV/RJ45/Audio/Display Port | |||
| Bezel Width | 1.7mm/3.5mm | 1.8mm/3.5mm | 0.88mm/1.7mm/1.8mm/3.5mm | 3.5mm |
| Brightness | 500cd/m2&700cd/m2 | 500cd/m2&700cd/m2 | 500cd/m2&700cd/m2 | 700cd/m2 |
| Resolution | 1920*1080 | 1920*1080 | 1920*1080 | 3840*2160 |
| Power supply | AC100-240V/50-60Hz | |||
| Sleep mode | 0.5W | |||
| Max comsumption | 180W | 200w | 220w | 350w |
| Net weight | 20kg | 25kg | 28kg | 40kg |
| Working Temp | 0-40℃ | |||
| Working Humidity | 10-90% | |||
| Operation | 7x24hrs | |||
| Life | >60,000hrs | |||
| Warranty | Standard one year without artificial damage,can be extended to 3 years,lifelong maintenance | |||
Pre-sales Services for lcd video wall
•Reply your inquiry in 24 working hours.
•Experienced staffs answer all your questions in fluent English.
•Customized requirement is available, OEM&ODM are welcome.
•Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
After-sales Services for lcd video wall
Terrific after-sales service:24 hours around the clock &12 months Warranty
Life-long maintenance service for the product
