46" Intelligent Split Multi Screen Video Wall , Hd Video Wall With 178° Wide Angle

Basic Information
Place of Origin: China
Brand Name: YD
Certification: ISO9001 , CE , RoHS , FCC
Model Number: LCD Video Wall
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Carton Box, Wooden Frame / Case, Flight Case
Delivery Time: 20 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 3 , 000pcs per month
Installation: Wall-Mounted/Floor Standing Application: Indoor
Resolution: 1920*1080 Brigjtness: 300cd/m2
Refresh Rate: 60Hz Transport Package: Carton Box, Wooden Frame / Case, Flight Case
Panel Size: 46 Inch Feature: Good Vision Effect
Interface: HDMI / VGA / DVI / AV/AUDIO /RS232 Brand: Samsung/LG/BOE
High Light:

commercial video wall


digital wall display

46" High Quality Intelligent Split Screen LCD Video Wall 1920x1080 Resolution with Good Vision Effect Rich Color


LCD Video Wall Key features:


LED direct-lit backlight with uniform brightness and no boundary shadow.

Resolution: 1920 x 1080

High display resolution, and delicate image with rich color;

High definition, high brightness, high color gamut

DID LCD screen with 178° wide angle.

Large display area with light weight

Longer display lifespan

Multiple jointing methods, applicable for various scenes.

Stable running and low maintenance cost, support 24 hours continuous wokring.

Metal case enhances the function of anti-radiation, anti-magnetic filed and strong electric field interference.

Working humidity: 10% ~ 90%, able to work under harsh envionment.


46" Intelligent Split Multi Screen Video Wall , Hd Video Wall With 178° Wide Angle 0


LCD Video Wall Specifications


Panel Size 46"(16:9) lcd video wall
Outer case Size 1021.98 x 576.57x 155 mm
Viewing Size 1018.08 x 572.67mm
Resolution 1920 x1080
Contrast ratio 3500:1
Brightness 450cd/m2
The Gap between panels 5.3mm
Power 300W
Response Time 8ms
Color 16.7M
Control Signal RS232
Viewing Angle V:178°, H:178°
Spliced quantity Any M line x Any N Row
Using Temperature 0℃-60℃
Using Humidity 10%-90%
Installation Floor standing, wall mount
Input Signal 1 x USB, 1 x HDMI in, 2 x DVI in, 1 x VGA in, 1 x AV in, 1 x AV out, 1 x Audio out, 1 x RS232 in, 1x RS232 out.


LCD Video Wall Quick Details:


1. Support a variety of signal ports.

2. Built-in splicing module, Support splice function

3. Support Creating one window PIP across the screen, roaming service, scaling,PIP

4. Support matrix joint control.
